GameApi::DistanceFloatVolumeApi Class Reference

#include <GameApi.hh>

Public Member Functions
IMPORT	DistanceFloatVolumeApi (Env &e)
IMPORT FD	function (std::function< float(float x, float y, float z)> f)
IMPORT FD	fd_sphere (PT center, float radius)
IMPORT FD	fd_cube (float start_x, float end_x, float start_y, float end_y, float start_z, float end_z)
IMPORT FD	fd_round_cube (float start_x, float end_x, float start_y, float end_y, float start_z, float end_z, float r)
IMPORT FD	fd_torus (float radius_1, float radius_2)
IMPORT FD	fd_cone (float c_x, float c_y)
IMPORT FD	fd_plane (float n_x, float n_y, float n_z, float n_w)
IMPORT FD	fd_hex_prism (float h_x, float h_y)
IMPORT FD	fd_tri_prism (float h_x, float h_y)
IMPORT FD	fd_triangle (PT a, PT b, PT c)
IMPORT FD	fd_quad (PT a, PT b, PT c, PT d)
IMPORT FD	fd_line (PT start, PT end, float dist)
IMPORT FD	fd_color (FD fd, float r, float g, float b, float a)
IMPORT FD	fd_rot_x (FD fd, float angle)
IMPORT FD	fd_rot_y (FD fd, float angle)
IMPORT FD	fd_rot_z (FD fd, float angle)
IMPORT FD	fd_trans (FD fd, float dx, float dy, float dz)
IMPORT FD	fd_min (FD a1, FD a2)
IMPORT FD	fd_max (FD a1, FD a2)
IMPORT FD	fd_and_not (FD a1, FD a2)
IMPORT FD	fd_blend (FD a1, FD a2, float k)
IMPORT FD	recalculate_normals (FD fd)
IMPORT FD	ambient_occulsion (FD fd, float d, float i)
IMPORT P	distance_poly (EveryApi &ev, FD fd, float dx, float dy, float dz, int sx, int sy, float ssx, float ssy, int ssxi, int ssyi, float ssx2, float ssy2)
IMPORT P	distance_poly_cyl (EveryApi &ev, FD fd, float pos_x, float pos_y, float pos_z, float dx, float dy, float dz, int sx, int sy, float ssx, float ssy, int ssxi, int ssyi, float ssx2, float ssy2)
IMPORT P	distance_poly_sph (EveryApi &ev, FD fd, float dx, float dy, float dz, int sx, int sy, float ssx, float ssy, int ssxi, int ssyi, float ssx2, float ssy2)
IMPORT PT	ray_shape_intersect (FD shape, PT pos, V vec)
IMPORT BM	render (FD obj, PT pos, V u_x, V u_y, V u_z, int sx, int sy)
IMPORT BM	render2 (EveryApi &ev, FD obj, int sx, int sy)
IMPORT std::string	shader_func (std::string name, FD obj, COV color)

Constructor & Destructor Documentation

DistanceFloatVolumeApi()

GameApi::DistanceFloatVolumeApi::DistanceFloatVolumeApi

(

Env &

e

)

Here is the caller graph for this function:

Member Function Documentation

ambient_occulsion()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::ambient_occulsion	(	FD	fd,
		float	d,
		float	i )

Here is the caller graph for this function:

distance_poly()

EXPORT GameApi::P GameApi::DistanceFloatVolumeApi::distance_poly	(	EveryApi &	ev,
		FD	fd,
		float	dx,
		float	dy,
		float	dz,
		int	sx,
		int	sy,
		float	ssx,
		float	ssy,
		int	ssxi,
		int	ssyi,
		float	ssx2,
		float	ssy2 )

Here is the caller graph for this function:

distance_poly_cyl()

EXPORT GameApi::P GameApi::DistanceFloatVolumeApi::distance_poly_cyl	(	EveryApi &	ev,
		FD	fd,
		float	pos_x,
		float	pos_y,
		float	pos_z,
		float	dx,
		float	dy,
		float	dz,
		int	sx,
		int	sy,
		float	ssx,
		float	ssy,
		int	ssxi,
		int	ssyi,
		float	ssx2,
		float	ssy2 )

Here is the caller graph for this function:

distance_poly_sph()

EXPORT GameApi::P GameApi::DistanceFloatVolumeApi::distance_poly_sph	(	EveryApi &	ev,
		FD	fd,
		float	dx,
		float	dy,
		float	dz,
		int	sx,
		int	sy,
		float	ssx,
		float	ssy,
		int	ssxi,
		int	ssyi,
		float	ssx2,
		float	ssy2 )

Here is the caller graph for this function:

fd_and_not()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::fd_and_not	(	FD	a1,
		FD	a2 )

Here is the caller graph for this function:

fd_blend()

GameApi::FD GameApi::DistanceFloatVolumeApi::fd_blend	(	FD	a1,
		FD	a2,
		float	k )

Here is the caller graph for this function:

fd_color()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::fd_color	(	FD	fd,
		float	r,
		float	g,
		float	b,
		float	a )

Here is the caller graph for this function:

fd_cone()

IMPORT FD GameApi::DistanceFloatVolumeApi::fd_cone	(	float	c_x,
		float	c_y )

fd_cube()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::fd_cube	(	float	start_x,
		float	end_x,
		float	start_y,
		float	end_y,
		float	start_z,
		float	end_z )

Here is the caller graph for this function:

fd_hex_prism()

IMPORT FD GameApi::DistanceFloatVolumeApi::fd_hex_prism	(	float	h_x,
		float	h_y )

fd_line()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::fd_line	(	PT	start,
		PT	end,
		float	dist )

Here is the caller graph for this function:

fd_max()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::fd_max	(	FD	a1,
		FD	a2 )

Here is the caller graph for this function:

fd_min()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::fd_min	(	FD	a1,
		FD	a2 )

Here is the caller graph for this function:

fd_plane()

IMPORT FD GameApi::DistanceFloatVolumeApi::fd_plane	(	float	n_x,
		float	n_y,
		float	n_z,
		float	n_w )

fd_quad()

IMPORT FD GameApi::DistanceFloatVolumeApi::fd_quad	(	PT	a,
		PT	b,
		PT	c,
		PT	d )

fd_rot_x()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::fd_rot_x	(	FD	fd,
		float	angle )

Here is the caller graph for this function:

fd_rot_y()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::fd_rot_y	(	FD	fd,
		float	angle )

Here is the caller graph for this function:

fd_rot_z()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::fd_rot_z	(	FD	fd,
		float	angle )

Here is the caller graph for this function:

fd_round_cube()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::fd_round_cube	(	float	start_x,
		float	end_x,
		float	start_y,
		float	end_y,
		float	start_z,
		float	end_z,
		float	r )

Here is the caller graph for this function:

fd_sphere()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::fd_sphere	(	PT	center,
		float	radius )

Here is the caller graph for this function:

fd_torus()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::fd_torus	(	float	radius_1,
		float	radius_2 )

Here is the caller graph for this function:

fd_trans()

GameApi::FD GameApi::DistanceFloatVolumeApi::fd_trans	(	FD	fd,
		float	dx,
		float	dy,
		float	dz )

Here is the caller graph for this function:

fd_tri_prism()

IMPORT FD GameApi::DistanceFloatVolumeApi::fd_tri_prism	(	float	h_x,
		float	h_y )

fd_triangle()

IMPORT FD GameApi::DistanceFloatVolumeApi::fd_triangle	(	PT	a,
		PT	b,
		PT	c )

function()

IMPORT FD GameApi::DistanceFloatVolumeApi::function

(

std::function< float(float x, float y, float z)>

f

)

ray_shape_intersect()

EXPORT GameApi::PT GameApi::DistanceFloatVolumeApi::ray_shape_intersect	(	FD	shape,
		PT	pos,
		V	vec )

recalculate_normals()

EXPORT GameApi::FD GameApi::DistanceFloatVolumeApi::recalculate_normals

(

FD

fd

)

Here is the caller graph for this function:

render()

EXPORT GameApi::BM GameApi::DistanceFloatVolumeApi::render	(	FD	obj,
		PT	pos,
		V	u_x,
		V	u_y,
		V	u_z,
		int	sx,
		int	sy )

Here is the caller graph for this function:

render2()

EXPORT GameApi::BM GameApi::DistanceFloatVolumeApi::render2	(	EveryApi &	ev,
		FD	obj,
		int	sx,
		int	sy )

Here is the caller graph for this function:

shader_func()

IMPORT std::string GameApi::DistanceFloatVolumeApi::shader_func	(	std::string	name,
		FD	obj,
		COV	color )

---

The documentation for this class was generated from the following files:

• GameApi.hh
• GameApi.cc
• GameApi_vo.cc
